CNC router
Cutting
Profile cutting in aluminium, acrylic, ply and sheet plastics.
3048mm
Bed length
Render- Bed size
- 1524mm × 3048mm
- Z-axis clearance
- 150mm
- Spindle power
- 10.8HP, 24,000rpm, HSD HSK63 quick-release spindle
Five machines, one building.
Nothing here is sub-contracted. A part that needs cutting, shearing, folding and welding is handled by one shop in Irvine, which is why we can turn work round quickly and answer for the finish.
RenderRenderLaser cutter
Cutting
Fibre laser cutting metal (steel, galvanised steel, aluminium, brass and stainless) to your drawing.
610mm
Bed length
Render- Source type
- Fibre
- Power
- 1200W
- Bed size
- 610mm × 610mm
- Materials
- Steel, galvanised steel, aluminium, brass, stainless
Guillotine
Shearing
Straight shearing of sheet to size before folding.
3165mm
Max cut length
Render- Max cut length
- 3165mm
- Max thickness, aluminium
- 4.5mm
- Max thickness, steel
- 3mm
- Max thickness, stainless
- 2mm
Folder
Forming
Flashings, cappings, fascias, soffits, rainwater goods and formed panels.
3100mm
Max fold length
Render- Max fold length
- 3100mm
- Max thickness
- Steel 2mm · Aluminium 3mm · Stainless 1.25mm
- Folding tooling
- Round rail wide offset (66/24mm), 4mm radius
- Minimum flange
- To be confirmed
Welding & fixture table
Joining
Brackets, frames and fabricated assemblies welded and held square on a dedicated fixture table.
TBC
Table size
Render- Table size
- To be confirmed
- Welding processes
- Laser welding, MIG and TIG
- Material thicknesses
- Laser welding: stainless, steel and galvanised steel 0.5–5mm, aluminium 1–5mm, brass 0.5–5mm
